Calibrations

LOAD CELLS

Up to 400 kip

DISPLACEMENT

Up to 40 inches

TORQUE

Up to 1 million in/lbs

ANGLE

Up to 360 degrees

SPEED

Up to 99,000 RPM

TEMPERATURE

Thermocouple Simulation
Types J, K, T, E, R, S, B, N

  • Range: -10 °C to +122 °C

  • CMC2: +0.62 °F (Ref: Omega CL543)

Temperature Probe

  • Range: -10 °C to +122 °C

  • CMC2: +0.46 °F (Ref: Fluke 9102S)

Pyrometer

  • Range: +20 °F to +752 °F

  • CMC2: +4.6 °F (Ref: Omega BB703)

DRYWELLS

  • Three (3) available; one with capability to +30 °F

DIMENSIONAL

  • Up to 100 inches

ANALOG SIGNALS- DC and Low Frequency

DC Voltage – Generate

  • Range: 0 to 35 VDC

  • CMC2, 6 (±): 0.019 V (Ref: B&K Precision 1770)

DC Voltage – Measure

  • Range: 0 to 30 VDC

  • CMC2, 6 (±): 0.009 V (Ref: Fluke 45)

Pressure

  • To 1500 PSI (103.4 Bar)

Upgrades/Repairs

200Kip Frame Designed and Built By Servo Innovations

TEST FRAMES

  • Controller
  • Actuator
  • LVDT
  • Load and Torque Cells
  • Design, Build, and Install Custom Frames

HYDRAULIC SYSTEMS

Soil Tester Upgraded By Servo Innovations

  • Chiller
  • Servo Valve
  • Manifold
  • Accumulators
  • Filters
  • Hoses and Lines

Other Services Offered

Technical/Auditing Support

Troubleshooting and System Analysis

Field Engineering Services

Proactive Diagnostic Inspections and Reporting

Hydraulic Maintenance Contracts

In-House or Offsite Training Seminars

Predictive Maintenance Plan Development and Implementation

Automotive Test Engineering Consulting Services
